The Caterpillar 303.5E2 CR Mini Excavator: A Comprehensive Overview

The Caterpillar 303.5E2 CR is a versatile and powerful machine that can be used for a variety of applications. It has an operating weight of 8207.81 lbs and is powered by a turbocharged diesel engine that offers excellent fuel efficiency. This machine is perfect for construction, landscaping, and other heavy-duty tasks. In this article, we'll provide an overview of the Caterpillar 303.5E2 CR Mini, its most common uses, and the cost of renting or purchasing it.

Specifications

AtributoCantidad
Precio del modelo$65,500
Precio de alquiler diario$390
Precio de alquiler de medio día$195
Precio de alquiler semanal$970
Peso operativo (libras)8207.81
Coste de mantenimiento por hora$7
Costo de mantenimiento mensual$590
Costo de combustible por mes$0
Consumo de combustible por hora (galones)0
Pagos mensuales de financiación (nuevo)$0
Pagos de financiación mensuales (usados)$0

Overview of the Caterpillar 303.5E2 CR Mini Excavator

The Caterpillar 303.5E2 CR Mini Excavator is a medium-sized excavator with a maximum dig depth of 10.2 feet and an operating weight of 8207.81 lbs. It's powered by a turbocharged diesel engine that produces 54 horsepower and offers excellent fuel efficiency. This machine is perfect for construction, landscaping, and other heavy-duty tasks. It's equipped with a variety of features, including a hydraulic thumb, a quick-attach system, and a ride-on platform.

Caterpillar 303.5E2 CR Mini: Key Features

ALL DAY COMFORT

  • Choose either a canopy or a sealed and pressurized cab which can be equipped with air conditioning, adjustable wrist rests, and a suspension seat option to help keep you working comfortably all day long.

EASY TO OPERATE

  • Controls are easy to use and the intuitive Next Generation LCD monitor provides easy to read machine information. An advanced touchscreen monitor can also be equipped.

STICK STEER TRAVEL MODE

  • Moving around the job site is even easier with the Cat Stick Steer option. Easily switch from traditional travel controls with levers and pedals to joystick controls to move the machine and to operate the blade. The benefit of less effort and improved control is in your hands!

BIG PERFORMANCE IN A COMPACT DESIGN

  • Strong lift and dig performance helps you get the job done faster. The compact radius design lets you access and work in the tightest areas. Dozer float allows for easy clean up.

SAFETY ON THE JOB SITE

  • Your safety is our top priority. The Cat mini excavator is designed to help keep you safe on the job. Courtesy work lights and a fluorescent retractable seat belt with optional seat belt reminder system are just a couple of the safety features we’ve built into the machine.

SIMPLE SERVICE FOR LESS DOWNTIME

  • Maintenance is quick and easy on the Cat mini excavator. Routine check points are easy to access at ground level through the side doors. The unique tilt up cab or canopy lets you reach additional service areas when needed.

LOWER OPERATING COSTS

  • Equipped with features such as auto idle, auto engine shutdown, and efficient hydraulics with a variable displacement pump, the Cat mini excavator was designed with reducing your operating costs in mind.

UNMATCHED DEALER SUPPORT

  • Your Cat dealer is here to help you reach your business goals. From providing equipment solutions to operator training to service needs and beyond, your Cat dealer is ready to help.

SUSTAINABILITY

  • The Cat® C1.1 engine meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards.

  • Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) * or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details.

  • Auto Idle helps reduce unnecessary fuel burn and greenhouse gas emissions by allowing the engine to automatically go into idle mode when the machine is not working.

  • Engine Idle Shutdown Timer reduces fuel burn, greenhouse gas emissions and unnecessary idle time by shutting down the machine after a pre-set idling period.

  • Cruise control helps you maintain a constant speed as you travel across your jobsite saving fuel and reducing greenhouse gas emissions.

  • The Cat® Seat Belt Reminder provides audible and visual warnings to remind operators to buckle up during machine operation. The easy-to-install system is compatible with all equipment brands to help ensure operator safety.

  • Extended maintenance intervals not only reduce downtime but decrease the amount of fluid and filters that are replaced over the life of the machine.

  • Remote Flash minimizes downtime and maintenance time while keeping your asset running with maximum efficiency. Alerts for machine updates are sent virtually from your Cat dealer and updates can be deployed without a dealer technician needing to be onsite.(if equipped)

  • Remote Troubleshoot decreases maintenance time and keeps your machine running with maximum efficiency by allowing your Cat dealer to virtually test the machine while working. Once a problem is identified, a technician can fix it the first time, saving time and money.(if equipped)

*Engines with no after-treatment devices can use higher blends, up to 100% biodiesel. (for use of blends higher than 20% biodiesel, consult your Cat dealer)

Caterpillar 303 Specifications: A Closer Look

Swing System

Machine Swing Speed 10rpm

Swing - Right 50 degrees

Engine

Gross Power 24.8hp

Net Power 23.5hp

Displacement 104cu in

Bore 3.4in

Stroke 3.6in

Net Power - Iso 9249 23.5hp

Engine Model Cat C1.7

Rated Net Power - Iso 9249 23.5hp

Note

Cat C1.7 engine meets U.S. EPA Tier 4 Final/EU Stage IIIB emission standards.

Operational

Operating Weight 8209lb

Weights

Note

Weight includes rubber tracks, bucket, operator, full fuel and auxiliary lines.

Operating Weight - With Cab 8209lb

Operating Weight - With Canopy 7803lb

Blade

Height 13in

Width 5.9ft in

Hydraulic System

Pump Flow 26.4gal/min

Note

Load sensing hydraulics with variable displacement piston pump.

Blade

Lift Height 16in

Dig Depth 19in

Hydraulic System

Operating Pressure - Swing 3132 psi

Operating Pressure - Equipment 3553 psi

Operating Pressure - Travel 3553 psi

Digging Force - Stick - Standard 4249lb

Digging Force - Stick - Long 3799lb

Digging Force - Bucket 7419lb

Auxiliary Circuit - Primary 18.5 gal/min

Auxiliary Circuit - Secondary 6.6 gal/min

Operating Specifications

Maximum Dig Depth 125in

Service Refill Capacities

Cooling System 1.5gal

Fuel Tank 12.2gal

Hydraulic Tank 11.2gal

Hydraulic System 17.2gal

Engine Oil 1.8gal

Travel System

Maximum Traction Force - High Speed 3822lb

Maximum Traction Force - Low Speed 6992lb

Travel Speed - High 2.9mph

Travel Speed - Low 2mph

Ground Pressure - 4.6 psi

Standard Equipment

ENGINE

Cat C1.1 Turbo Engine (U.S. EPA Tier 4 Final/EU Stage V)

Automatic Engine Idle

Automatic Engine Shutdown

Automatic Two Speed Travel

Fuel Water Separator

Power on Demand (not available in all regions)

Variable Displacement Piston Pump

Load Sensing/Flow Sharing Hydraulics

HYDRAULICS

Smart Tech Electronic Pump

Accumulator

Automatic Swing Brake

Auxiliary Hydraulic Lines

One and Two Way Auxiliary Flow

Continuous Auxiliary Flow

Auxiliary Line Quick Disconnects

GUARDING

Top Guard ISO 10262:1998 Level I

OPERATOR ENVIRONMENT

Tilt-up Canopy or Tilt-Up Cab

ROPS – ISO 12117-2:2008

TOPS – ISO 12117:1997

Next Generation Advanced Monitor
– Touch Screen
– Site Reference System
– High Definition Camera Capable (IP68 and IP69K)
– Numeric Security Code

Stick Steer Mode

Travel Cruise Control

Control Pattern Changer (optional in some regions)

Adjustable Wrist Rests

Washable Floor Mat

Travel Pedals and Hand Levers

Machine Security

Machine Security – Standard Key with Pass Code

Fabric Suspension Seat (Cab only)

Vinyl Suspension Seat (Canopy only)

Hydraulic Lockout – All Controls

Retractable High Visibility Seat Belt (75 mm/3 in)

Coat Hook

Cup Holder

Storage Pocket

Skylight

Mounting Bosses for Front

Signaling/Warning Horn

Interior Light (Cab only)

Boom Light, Halogen

Utility Space for Mobile Phone

Next Generation Color LCD Monitor (IP66)
– Fuel Level and Coolant Temperature Gauges
– Maintenance and Machine Monitoring
– Performance and Machine Adjustments
– Numeric Security Code
– Multiple Languages
– Hour Meter with Wake Up Switch
– Jog Dial (cab only)

UNDERCARRIAGE

Rubber Belt (300 mm/11.8 in wide)

Dozer Blade

Dozer Blade Float

Tie Downs on Track Frame

BOOM, STICK AND LINKAGES

One Piece Boom (2200 mm/86.6 in)

Standard Stick (1260 mm/49.6 in)

Front Shovel Capable – Hydraulic Coupler

Front Shovel Capable – Pin-On

Thumb Ready (not available in all regions)

Certified Lifting Eye (optional in some regions)

ELECTRICAL

12 Volt Battery

Software (machine and monitor)

Maintenance Free Battery

Signaling/Warning Horn

12 Volt Power Socket

Most Common Uses

The Caterpillar 303.5E2 CR Mini Excavator is a versatile machine that can be used for a variety of applications. It's perfect for construction and landscaping tasks, such as excavating, digging trenches, and grading. It's also suitable for demolition work, as it is powerful enough to break through concrete and other hard surfaces. Additionally, this machine can be used for material handling, such as loading and unloading materials from trucks and trailers.

Cost of Renting or Purchasing

The cost of purchasing the Caterpillar 303.5E2 CR Mini Excavator is $65,500. Renting this machine for a day costs $390, while renting it for a half day costs $195. If you need to rent it for a week, the cost is $970. Additionally, the estimated monthly maintenance costs are around $250, while the estimated fuel cost per month is around $200. The estimated hourly fuel cost is $2.50.

Similar Models

If you're looking for a similar model to the Caterpillar 303 CR Mini Excavator, there are several other machines you may want to consider. The Caterpillar 304E2 CR is a smaller excavator with an operating weight of 6,924 lbs and a maximum dig depth of 8.2 feet. The Caterpillar 305E2 CR is a medium-sized excavator with an operating weight of 8,984 lbs and a maximum dig depth of 10.2 feet. The Caterpillar 307E2 CR is a larger excavator with an operating weight of 11,827 lbs and a maximum dig depth of 12.2 feet. You can check out these models Caterpillar 304E2 CR, Caterpillar 305E2 CR, and Caterpillar 299D.

Conclusion

The Caterpillar 303.5E2 CR Mini Excavator is a powerful and versatile machine that is perfect for construction, landscaping, and other heavy-duty tasks. It has an operating weight of 8207.81 lbs and is powered by a turbocharged diesel engine that offers excellent fuel efficiency. The cost of purchasing the machine is $65,500, while the cost of renting it for a day is $390. Additionally, the estimated monthly maintenance costs are around $250, while the estimated fuel cost per month is around $200. If you're looking for a similar model, you may want to consider the Caterpillar 304E2 CR, the Caterpillar 305E2 CR, or the Caterpillar 307E2 CR.
