Dynapac Cc1200

Compactors / Double drum vibratory rollers

Introducing the Dynapac CC1200: A Comprehensive Overview

The Dynapac CC1200 is a reliable, powerful, and versatile machine designed to help you get the job done quickly and efficiently. This robust compactor is great for a variety of projects, including road construction, soil compaction, and asphalt paving. With an operating weight of 7500 kg and a maximum centrifugal force of 40 kN, the CC1200 is capable of tackling even the toughest jobs.

Specifications

AttributeAmount
Model Price$57,812
Daily rental price$400
Half day rental price$200
Weekly rental price$1,200
Operating weight (pounds)7500
Maintenance cost per hour$6
Monthly maintenance cost$520
Fuel cost per month$0
Hourly fuel consumption (gallons)0
Monthly financing payments (new)$0
Monthly financing payments (used)$0

Dynapac CC1200: At a Glance
Double drum vibratory rollers

Operating Mass: 2600 kg

SLL (front/rear): 10.5/ 11.3 kg/cm

Compaction width: 1200 mm

Centrifugal force 7,420/8,170 lb

Nominal amplitude 0.020 in

Static linear load (front/rear) 59 /63 lbs/in

Vibration frequency 3,780/3,960 vpm

Water tank 42 gal

Dimensions

Wheelbase      1700 mm

Width  1340 mm

Curb clearance            554 mm

Drum diameter           702 mm

Height, with ROPS/cab           2542 mm

Height, w/o ROPS/cab 1744 mm

Ground clearance       180 mm

Length 2400 mm

Overhang, right           70 mm

Overhang, left 70 mm

Turning radius, outside           3770 mm

Turning radius, inside 2570 mm

Drum shell thickness  13 mm

Drum width     1200 mm

Steering angle ±30°

Engine / Drive

Manufacturer/Model Kubota D1703-M (T4i)

Type    Water cooled diesel engine

Rated power, SAE J1995         26 kW (35 hp ) @ 2800 rpm

Fuel tank capacity       50 l

Common Uses of the Dynapac CC1200

The Dynapac CC1200 is a great machine for a variety of applications. It is commonly used for soil compaction, road construction, and asphalt paving. The machine is also great for trenching and other construction projects. The centrifugal force generated by the machine helps to ensure that the job is done quickly and efficiently.

Hydraulic System

Driving Axial piston pump with variable displacement. Radial piston motors (2) with constant displacement.

Vibration Gear pump/motors with constant displacement.

Steering Gear pump with constant displacement

Service brake Hydrostatic in forward and reverse lever.

Parking/Emergency brake Failsafe multidisc brake in both drums.

Price and Rental Options

The CC1200 has a retail price of $57,812. If you need the machine for a day, you can rent it for $400. If you need it for a half day, you can rent it for $200. If you need it for a week, you can rent it for $1200.

Maintenance and Fuel Costs

The estimated monthly maintenance costs for the Dynapac CC1200 are $50. The estimated fuel cost per month is $200. The hourly fuel cost estimation is $1.50.

Similar Models

If you are looking for a model that is similar to the Dynapac CC1200, you may want to consider the Volvo SD100D, the Cat CS56B, or the Bomag BW145PD-4. All of these models offer similar features and capabilities as the Dynapac CC1200. You may also want to consider HAMM HD12VV and HAMM 3307.

Conclusion

The Dynapac CC1200 is a powerful and reliable machine that is perfect for a variety of applications. With an operating weight of 7500 kg and a maximum centrifugal force of 40 kN, the Dynapac CC1200 is capable of tackling even the toughest jobs. The estimated monthly maintenance costs are $50, and the estimated fuel cost per month is $200. If you are looking for a similar model, you may want to consider the Volvo SD100D, the Cat CS56B, or the Bomag BW145PD-4. Feel free to connect with us if you have further questions, and don't forget to share this page.
