Cat 320DL Specs: A Closer Look

Boom/Stick Option (Hex) 1

Shipping Length Of Unit - 31ft in

Shipping Height Of Unit - 12.25ft in

Max Cutting Height - 32.58ft in

Max Loading Height - 22.75ft in

Max Reach Along Ground - 35.33ft in

Max Vertical Wall Digging Depth - 22.83ft in

Max Digging Depth - 25.17ft in

Boom/Stick Option (Hex) 1

Boom 18\'7\" (5680mm) / Stick 12\'8\" (3900mm) -Reach

Boom/Stick Option (Hex) 2

Shipping Length Of Unit - 31ft in

Max Cutting Height - 31.17ft in

Shipping Height Of Unit - 9.92ft in

Max Loading Height - 21.33ft in

Max Reach Along Ground - 32.33ft in

Max Vertical Wall Digging Depth - 19.93ft in

Max Digging Depth - 22.08ft in

Boom/Stick Option (Hex) 2

Boom 18\'7\" (5680mm) / Stick 9\'7\" (2900mm) -Reach

Boom/Stick Option (Hex) 3

Shipping Length Of Unit - 31ft in

Max Cutting Height - 30.5ft in

Max Loading Height - 20.67ft in

Shipping Height Of Unit - 10ft in

Max Reach Along Ground - 31ft in

Max Vertical Wall Digging Depth - 18.5ft in

Max Digging Depth - 20.67ft in

Boom/Stick Option (Hex) 3

Boom 18\'7\" (5680mm) / Stick 8\'2\" (2500mm) -Reach

Boom/Stick Option (Hex) 4

Shipping Length Of Unit - 29.67ft in

Shipping Height Of Unit - 10.75ft in

Max Cutting Height - 29.33ft in

Max Loading Height - 18.75ft in

Max Reach Along Ground - 29.42ft in

Max Digging Depth - 19.33ft in

Boom/Stick Option (Hex) 4

Boom 17\'1\" (5200mm) / Stick 7\'10\" (2400mm) -Reach

Max Vertical Wall Dig Depth - 17.58ft in

Boom/Stick Option (Hex) 5

Shipping Length Of Unit - 41.58ft in

Shipping Height Of Unit - 10.5ft in

Max Cutting Height - 31ft in

Max Loading Height - 19.75ft in

Max Reach Along Ground - 31.92ft in

Max Digging Depth - 21.5ft in

Boom/Stick Option (Hex) 5

Boom 29\'1\" (8850mm) / Stick 20\'7\" (6280mm) -Reach

Max Vertical Wall Dig Depth - 16.33ft in

Dimensions

Ground Clearance - 1.5ft in

Height To Top Of Cab - 9.67ft in

Width To Outside Of Tracks - 9.9ft in

Length Of Track On Ground - 10.75ft in

Tail Swing Radius - 9ft in

Counterweight Clearance - 3.35ft in

Shipping Length - 30.98ft in

Shipping Height - 11.3ft in

Removal Counterweight Clearance - 3.33ft in

Transport Width - 10.44ft in

Undercarriage

Track Gauge - 7.25ft in

Shoe Size - 24in

Max Travel Speed - 3.5mph

Drawbar Pull - 46085.82lb

Engine

Engine Make - 2236

Engine Model - C6.4 ACERT

Net Power - 148hp

Power Measured @ - 1800rpm

Displacement - 389cu in

Bore - 4.1in

Stroke - 5.2in

Net Power - Iso 9249 - 148hp

Net Power - Sae J1349 - 148hp

Engine Model - Cat C6.4 ACERT

Net Power - Eec 80/1269 - 148hp

Net Flywheel Power - 148hp

Operational

Operating Weight - 44820lb

Fuel Capacity - 108gal

Cooling System Fluid Capacity - 6.6gal

Hydraulic System Fluid Capacity - 69gal

Engine Oil Capacity - 8gal

Operating Voltage - 24V

Swing Drive Fluid Capacity - 2.1gal

Alternator Supplied Amperage - 50amps

Hydraulic System Relief Valve Pressure - 5076psi

Hydraulic Pump Flow Capacity - 54gal/min

Swing Mechanism

Swing Torque - 45612lb ft

Swing Speed - 11.5rpm

Weights

Operating Weight - 44820lb

Operating Weight - Long Undercarriage - 47554lb

Operating Weight - Standard Undercarriage - 44820lb

Base Machine With Counterweight And 800 Mm Shoes - 38514.8lb

Buckets

Reference Bucket Capacity - 1.4yd3

Minimum Bucket Capacity - 0.6yd3

Maximum Bucket Capacity - 1.6yd3

Hydraulic System

Pilot System - Maximum Flow - 9 gal/min

Pilot System - Maximum Pressure - 566 psi

Maximum Pressure - Travel - 5076 psi

Maximum Pressure - Swing - 3553 psi

Maximum Pressure - Heavy Lift - 5076 psi

Main Implement System - Maximum Flow (2x) - 54 gal/min

Boom Cylinder - Bore - 4.7in

Boom Cylinder - Stroke - 49.6in

Maximum Pressure - Equipment - 5076 psi

B1 Family Bucket Cylinder - Bore - 4.7in

B1 Family Bucket Cylinder - Stroke - 43.5in

Reach Stick Cylinder - Bore - 5.5in

Reach Stick Cylinder - Stroke - 59.8in

Cb2 Family Bucket Cylinder - Bore - 5.3in

Cb2 Family Bucket Cylinder - Stroke - 45.5in

Mass Stick Cylinder - Bore - -5.5in

Mass Stick Cylinder - Stroke - 59.2in

Operating Specifications

Maximum Bucket Capacity - 2.6yd3

Maximum Cutting Height - 32.7ft in

Maximum Loading Height - 273.3in

Minimum Loading Height - 48.5in

Maximum Vertical Wall Digging Depth - 274.5in

Service Refill Capacities

Cooling System - 6.6gal

Final Drive - Each - 2.1gal

Hydraulic Tank - 32gal

Hydraulic System - Including Tank - 69gal

Engine Oil - 8gal

Fuel Tank Capacity - 108gal

Swing Drive - 2.1gal

Hydraulic Tank - Including Suction Pipe - 36gal

Standards

Brakes - SAE J1026 APR90

Cab/Fogs - SAE J1356 FEB88

Sound Performance

Performance - ANSI/SAE J1166 APR 90

Track

Standard With Long Undercarriage - 27.6in

Ground Clearance - Fixed Gauge - 17.72 in

Standard With Standard Undercarriage - 23.7in

Drive

Maximum Travel Speed - 3.5mph

Maximum Drawbar Pull - 46085.9lb

Common Uses

The Caterpillar 320D L is an excellent machine for a variety of applications. It is commonly used for digging trenches, excavating foundations, and loading and unloading materials. The 320D L is also suitable for demolition projects, as it has the power to tear down structures quickly and efficiently. Additionally, this machine is ideal for moving large objects, such as boulders and logs.

Price

The Caterpillar 320D L has a purchase price of $108,000. For those who don't want to purchase the machine outright, there are rental options available. The cost to rent the 320D L for a day is $725, while the cost to rent it for a half-day is $363. The cost to rent it for a week is $2,900.

Maintenance and Fuel Costs

The estimated monthly maintenance costs for the Caterpillar 320DL are approximately $700. The estimated fuel cost per month is approximately $2,000. The hourly fuel cost estimation for the 320D L is approximately $60.

Models Similar to the Caterpillar 320D L

If you are looking for a similar machine, there are several other models from Caterpillar that may be suitable. The Caterpillar 320E, the Caterpillar 320F, the Caterpillar 320, and the Caterpillar 320G are all similar models that offer similar features and capabilities.

Conclusion

The Caterpillar 320D L is a powerful and reliable excavator that is suitable for a variety of tasks. With an operating weight of 44820 and a purchase price of $108,000, this machine is an excellent choice for those who need a machine that can handle heavy-duty work. The estimated monthly maintenance and fuel costs are also reasonable, making the 320D L a great value for those who need a reliable machine. For those who don't want to purchase the machine outright, there are rental options available. There are also several models from Caterpillar that offer similar features and capabilities.
