Introducing the John Deere 160G LC: A Comprehensive Overview

John Deere 160G LC: Key Features

Engine

The EPA FT4/EU Stage IV engine employs field-proven cooled exhaust gas recirculation (EGR), high-uptime exhaust filters that are easy to maintain, and selective catalytic reduction (SCR)

Ash-service intervals for the diesel particulate filter (DPF) are condition based, with the machine notifying the operator before service is required.

Highly efficient hydraulically driven fans run only as fast as needed, reducing noise, fuel consumption, and operating costs. Reversing option automatically back-blows cooler cores to keep them clean. The cooling systems keep things running cool, even in high-trash environments and high altitudes.

Controls

Ergonomically correct short-throw pilot levers provide smooth, predictable fingertip control with less movement and effort.

Push buttons in the right lever allow predictable control of auxiliary hydraulic flow for operating attachments. Optional sliding switch provides proportional speed control.

Productivity

Three productivity modes allow you to choose the digging style that fits the job:

• High productivity delivers more power and faster hydraulic response to move more material.

• Power delivers a balance of power, speed, and fuel economy for normal operation.

• Economy limits top speed and helps save fuel.

Visibility

Hood design, expanded front and side glass, narrow front cab posts, overhead glass, and numerous mirrors provide optimal visibility.

Serviceability

Large fuel tanks and 500- and 5,000-hour engine and hydraulic oil-service intervals decrease downtime for routine maintenance. Fluid-sample and remote diagnostic ports help speed preventative maintenance and troubleshooting.

Arm & Boom

A John Deere exclusive, three welded bulkheads within the boom resist torsional stress for amazing durability.

John Deere 160G Specs

Driveline

Emission Rating Tier 4 / Stage IV

Engine Manufacturer John Deere Power Tech

Number Of Cylinders 4

Displacement, ltr (Inches³) 4.5 (275)

Rated speed, rpm 2200

Engine Output - Net, kW (hp) 90 (122) Number Of Carrier Rollers - Each Side 2

Number Of Track Rollers - Each Side 7

Track Shoe Width, mm (inches) 700 (28)

Dimensions

Transport Length Mono Boom, mm (ft/in) 8650 (28 ft 5 in)

Transport Height - Maximum, mm (ft/in) 3110 (10 ft 2 in)

Overall Undercarriage Width, mm (ft/in) 2690 (8 ft 10 in)

Track Length On Ground, mm (ft/in) 3100 (10 ft 2 in)

Overall Undercarriage Length, mm (ft/in) 3920 (12 ft 10 in)

Tailswing Radius, mm (ft/in) 2550 (8 ft 4 in)

Ground Clearance, mm (inches) 470 (19)

Width over fixed tracks, mm (ft/in) 2690 (8 ft 10 in)

Track Gauge, mm (ft/in) 1990 (6 ft 6 in)

Digging Reach - Mono Boom, mm (ft/in) 9330 (30 ft 7 in)

Ground Level Reach - Mono Boom, mm (ft/in) 9160 (30 ft 1 in)

Dig Height - Mono Boom, mm (ft/in) 9130 (29 ft 11 in)

Dump Height - Mono Boom, mm (ft/in) 6400 (21 ft )

Dig depth - 2.44m / 8'ft flat bottom, mm (ft/in) 6270 (20 ft 7 in)

Dig Depth - Mono Boom, mm (ft/in) 6490 (21 ft 4 in)

Standard Arm, mm (ft/in) 3100 (10 ft 2 in)

Capacities

Fuel Tank, ltr (gallons (US)) 285 (75.3)

Hydraulic Tank, ltr (gallons (US)) 125 (33)

Number Of Batteries 2

Voltage, V 24

Performance

Ground Bearing Pressure, kPa (PSI) 35 (5.08)

Swing Speed, rpm 13.3

Swing Torque, kNm (lbf / ft) 44 (32353)

Travel Speed - High, kph (mph) 5.3 (3.3)

Arm Tearout, kN (lbf) 82 (18508)

Bucket Breakout, kN (lbf) 119 (26665)

Gradeability, % 70

End lift - 7.5m Reach, kg (lbs) 3150 (6750)

Side lift - 7.5m Reach, kg (lbs) 1900 (4100)

Total Flow, lt/min (gallons (US) / min) 382 (101)

Bucket Pressure, bar (PSI) 343.36 (4980)

Boost Pressure, bar (PSI) 380 (5511)

Weights

Operating Weight, kg (lbs) 17945 (39526)

Common Uses

The 160G LC is an incredibly versatile machine, making it ideal for a variety of construction tasks. From digging trenches and foundations to lifting and moving heavy materials, this excavator is capable of completing any job with ease. It is also a great choice for demolition, earthmoving, and landscaping.

Pricing

The 160G LC comes with a hefty price tag of $218,664.87. You can also rent for a day for $750, for a half-day for $375, or for a week for $1800.

Maintenance and Fuel Costs

The 160G LC requires regular maintenance to keep it running at peak performance. The estimated monthly maintenance costs for the machine are around $150. As for fuel costs, the estimated monthly fuel cost is approximately $400. The hourly fuel cost estimation for the machine is about $10.

Similar Models

There are several models that are similar to the 160G LC, including the Deere 250G and the Deere 120G LC. The Deere 135G LC, the Deere 210G LC, Deere 200C LC, and the Deere 135G are also great options.

Conclusion

This multi-purpose excavator is designed for heavy lifting, digging, and other construction tasks. It's an incredibly powerful machine, capable of handling any construction job with ease. If you're in the market for a machine that can handle any task, the 160G LC is a great choice.
