Lull 1044C-54 Specs: A Closer Look

Engine

Make and Model John Deere 4045TF

Fuel No. 2 Diesel

Cycles 4

No. of Cylinders 4

Displacement 276 cu in (4.5 L)

Rated Speed 2,500 rpm

Max. Gross BHP 115 hp (85 kW)

Fuel Tank 36 gal (136 L)

Engine Block Heater

Engine Filters

Two-stage dry air cleaner—centrifugal pre-cleaner with continuous dust ejector plus replaceable primary dry filter element and safety element.

Visual service indicator.

Replaceable spin-on fuel filter. Full-flow replaceable spin-on engine oil filter.

Electrical System

Voltage: 12V

Alternator: 95 amp

Battery: 925 cold cranking amps at 0°F

Transmission

Modulated powershift.

4-speed forward and 3-speed reverse.

Axles

Full-time planetary 4-wheel drive.

Oscillating rear axle.

Service Brakes

Hydraulically actuated inboard wet disc brakes.

Parking Brakes

Spring applied hydraulic release brake with transmission declutch feature.

Tires

Standard: 400/75-28

Cab

Certified ROPS/FOPS structure.

Suspension seat

Steering wheel mounted horn.

Rear view mirrors.

Steering

4-wheel circle, 4-wheel crab, 2-wheel front.

Instruments

Hydraulic oil temperature, fuel level, tachometer, and hour meter gauges. Warning indicators for transmission oil temperature, hydraulic oil temperature, engine oil pressure, alternator charging, air filter restriction, hydraulic oil filter restriction, and low brake pressure. Indicators for parking brake and RAS System.

Controls

Multi-function, fully proportional pilot operated joystick controls for boom functions, carriage tilt, auxiliary control, frame leveling, and horizontal load placement system.

Hydraulic System

Load sensing dual gear pumps. 33.5 gal (127 L) system capacity.

Front Outriggers

Axle mounted high clearance outriggers allow frame leveling without changing stance.

Auxiliary Hydraulics

Used for all attachments equipped with cylinders or other hydraulic components. Consists of valves, controls, and hydraulic lines.

Dimensions

Length (less forks) 246 in. (6.24 m)

Width 101 in. (2.57 m)

Height 97 in. (2.46 m)

Wheelbase 124 in. (3.14 m)

Ground Clearance 16 in. (406 mm)

Outside Turning Radius 170 in. (4.32 m)

Maximum Reach from Front Tires to 24 in. (609 mm)

Load Center 45 ft (13.7 m)

Price and Rental Options

The Lull 1044C-54 II is priced at $49,950, so it provides significant value for the money. If you prefer not to purchase it, it's also available for rent, with a daily rate of $360, a half-day rate of $180, and a weekly rate of $1080.

Operating Weight and Maintenance Costs

This unit has an operating weight of 20,890 pounds, making it a great choice for heavier jobs. The estimated monthly maintenance costs for the forklift are around $200, which includes regular oil changes, filter replacements, and other routine maintenance.

Fuel Costs

The estimated fuel costs for this machine are around $200 per month. The hourly cost is estimated to be around $2.50, depending on the type of fuel used and the type of job being performed.

Similar Models

If you're looking for a similar model to the 1044C-54 II, there are several other options available. The 1044C-44 II is a slightly smaller model with a maximum lift capacity of 44,000 pounds, while the 1044C-54 III is a larger model with a maximum lift capacity of 54,000 pounds. The 1044C-64 II is the largest model in the series, with a maximum lift capacity of 64,000 pounds. The KUBOTA U25 and The SANY SSR120C-8 are part of a family of mini excavators.

Conclusion

The 1044C-54 II is a powerful forklift that'll ensure you efficiently tackle the toughest of jobs with ease. It's priced at $49,950, and is available for rental at a daily, half-day, or weekly rate. It has an operating weight of 20,890 pounds, and the estimated monthly fuel and maintenance costs are around $200 and $200, respectively. If you're looking for a similar model, there are several other options available, including the 1044C-44 II, the 1044C-54 III, and the 1044C-64 II.
