Enclosed Cab with HVAC (Optional)
Advanced Display with Backup Camera
Electro-hydraulic Joystick Controls
Heated, Air Suspension Seat (Optional)
Two-Speed Travel
High Flow XPS Hydraulic System (Optional)
Quick Coupler - Hydraulic (Optional)
Product Link System for Equipment Management
Emissions Reduction Technology (Tier 4 Final)
Anti-Theft System with Passcode Protection (Optional)
17.7 inch (450 mm) Triple Grouser Tracks
Self-Leveling Bucket
Automatic Engine Speed Control
Clearance Sonar for Obstacle Detection (Optional)
LED Work Lights (Optional)
Engine Power: 95 hp
Displacement: 232 cu in
Operating Weight: 10,533 lb
Fuel Capacity: 27.7 gal
Rated Operating Capacity: 4,500 lb
Tipping Load: 9,000 lb
Track Width: 15.7 in
Ground Pressure: 4.4 psi
Max Travel Speed: 8.4 mph
Hydraulic Flow: 23 gal/min
Hydraulic Pressure: 3,335 psi
Height to Bucket Hinge Pin: 126 in
Length of Track on Ground: 63.7 in
Width over Tracks: 76 in
Height to Top of Cab: 83.1 in
For your convenience, we've included these documents free to download so you can make the best decision.
