Enclosed Cab with HVAC
High Flow Hydraulics (Optional)
Pilot Controls with Adjustable Sensitivity
Anti-Theft System with Keyless Start
Vertical Lift Design
Two-Speed Travel
Self-Leveling Bucket Function
LCD Display with Advanced Diagnostics
LED Work Lights for Improved Visibility
Ride Control (Optional)
Hydraulic Quick Coupler
Sealed and Pressurized Cab for Reduced Noise and Dust
Reversible Fan (Optional)
Rearview Camera
Electro-Hydraulic Controls
Engine Power: 96.4 kW (131 hp)
Displacement: 3766 cc (230 cu in)
Operating Weight: 4675 kg (10,300 lbs)
Fuel Capacity: 109 L (28.8 gal)
Hydraulic System Fluid Capacity: 64 L (16.9 gal)
Track Width: 450 mm (17.7 in)
Ground Pressure: 35.5 kPa (5.15 psi)
Max Travel Speed: 11 km/h (6.8 mph)
Bucket Breakout Force: 3267 kgf (7,200 lbf)
Rated Operating Capacity: 1315 kg (2,900 lbs)
Tipping Load: 3756 kg (8,280 lbs)
