Ripper - Multi-Shank

4124 GD 5/23/24

8SU/U BULLDOZER, BASIC

ALTERNATOR, 150AMP STD

ARO, SINGLE TILT

BASIC ARRANGEMENT

BATTERIES, HEAVY DUTY

BLADE, 8SU W/RK GRD & WEAR PLT

BRAKES, BASIC

C15 ENGINE

CAB AR, SINGLE PANE

CAT CERTIFIED USED

CYLINDERS, LIFT, BASIC

ENGINE COOLANT, STD (-37C)

ENGINE, STANDARD

FINAL DRIVES, STANDARD

FLUIDS, STANDARD

FUEL SYSTEM, STANDARD

GAUGE, STANDARD

GRAB HANDLES, PUSH ARM

GUARD, FAN DEBRIS

GUARDS, BOTTOM, STANDARD

HEATER, ENGINE COOLANT 120V

LIGHTS, BASIC

LINES, SINGLE TILT

NO CARRIER ROLLERS

OIL CHANGE SYSTEM HIGH SPEED

Online Owner's Manual

OPERATORS AR, STANDARD

PRECLEANER, BASIC

PREMIUM CORP RADIO (12V)

PRICE UPDT: 09/24/24 VIA U1C2700

PRODUCT LINK, CELLULAR PLE742

PUSH ARMS

REAR HYDRAULICS, RIPPER

SEAT, AIR SUSPENSION

TOOTH, MULTI-SHANK RIPPER

TRACK, 610MM / 24" ES, PPR

UC, HD, SUSPENDED

VISIBILITY ARR, BASIC

Engine Manufacturer: Caterpillar

Engine Model: C15 ACERT

Emission Rating: Tier 3

Bore: 137mm

Stroke: 172mm

Final Drive: Double Reduction

Height - Max: 3461mm

Ground Clearance: 618mm

Track Length - On Ground: 3207mm

Blade: Semi U

Blade - Width: 3940mm

Blade - Height: 1690mm

Blade - Dig Depth: 575mm

Blade - Lift Clearance: 1225mm

Blade - Tilt: 883mm

Fuel Tank: 643ltr

Blade - Capacity: 8.7m³

Speed - Forward Maximum: 10.6kph

Drawbar Pull - Maximum: 618.5kN

Operating Weight: 38488kg

Media: Machine Brochure
