2023 Caterpillar 289D3 C3HF
- 1699 hours
- Ships nationwide
- #A2282488
+13 more2023 Caterpillar 289D3 C3HF
- 1699 hours
- Ships nationwide
- #A2282488
About this equipment
The 2023 Caterpillar 289D3 C3HF is a robust compact track loader designed for efficiency and comfort. It features an enclosed cab with HVAC, advanced display with backup camera, and optional high-end amenities like a heated air suspension seat and Bluetooth radio. With a 74.3 hp engine and an operating weight of 11,003 lb, it provides a breakout force of 5,886 lbf and a hydraulic flow of 23 gal/min. It includes a high flow XPS hydraulic system, ride control, and eco mode for fuel efficiency. This machine excels in functionality with a rated operating capacity of 3,700 lb, ensuring powerful performance in diverse working conditions.
Features
Enclosed Cab with HVAC
Advanced Display with Backup Camera
Electro-hydraulic Joystick Controls
Heated Air Suspension Seat (Optional)
High Flow XPS Hydraulic System (Optional)
Two Speed Travel
Sealed and Pressurized Cab for Reduced Noise and Dust Intrusion
Bluetooth Radio with Hands-free Calling (Optional)
LED Work Lights
Self-leveling Bucket Feature
Return-to-Dig and Work Tool Positioner
Ride Control System
Anti-theft System with Keyless Start
Reversible Fan for Radiator Cleaning (Optional)
Eco Mode for Improved Fuel Efficiency
Specifications
Engine Power: 74.3 hp
Displacement: 203.2 cu in
Net Power: 72.9 hp
Operating Weight: 11,003 lb
Fuel Capacity: 27.7 gal
Rated Operating Capacity: 3,700 lb
Tipping Load: 7,400 lb
Breakout Force: 5,886 lbf
Hydraulic Flow: 23 gal/min
Hydraulic Pressure: 3,335 psi
Travel Speed: 7.8 mph
Width Over Tracks: 78 in
Height to Bucket Hinge Pin: 131 in
Ground Clearance: 8.9 in
Cab Height: 83.2 in
